EJ1N

EJ1N

Multi loop in-panel temperature controller

EJ1N is designed to deliver an easy-to-use Multi-Point Control System able to optimize wiring job and space saving thanks to its modular approach

  • Reduce Crossover Wiring with Horizontal Connection Structure
    Simply connect power supply line and RS485 to end unit module to  power up the entire system
  • Available with screw terminals and screw-less clamp terminals
  • Fit in your machine configuration perfectly
    Up to 64 module (2 loops and/or 4 loops version) can be installed on the same communication RS485 line
  • All major sensors input type supported (thermocouple, Pt100, linear)
  • Simplify commissioning tasks thanks to extensive set of feature to make PID tuning effort easier
    2-PID algorithm to achieve both good step response and disturbance response, Independent Autotuning  for heating/cooling PID control, disturbance overshoot adjustment function for temperature fluctuation rejection.

Specifications & ordering info

Ordering information

Type Control points Control outputs Auxiliary outputs Other functions Terminal Order code
Basic unit 2 2 voltage (pulse) 2 transistor (NPN)
2
For heating/cooling control applications, the auxiliary outputs on the 2-point models are used for cooling control.
On the 4-point models, heating/cooling control can be performed for two input points only.
2 CT input
2
When using the heater burnout alarm, purchase a Current Transformer (E54-CT1 or E54-CT3) separately.
+ 2 event input
M3 screws EJ1N-TC2A-QNHB
Basic unit 2 2 voltage (pulse) 2 transistor (NPN)
2
For heating/cooling control applications, the auxiliary outputs on the 2-point models are used for cooling control.
On the 4-point models, heating/cooling control can be performed for two input points only.
2 CT input
2
When using the heater burnout alarm, purchase a Current Transformer (E54-CT1 or E54-CT3) separately.
+ 2 event input
Screw-less clamp EJ1N-TC2B-QNHB
Basic unit 2 2 current 2 transistor (NPN)
2
For heating/cooling control applications, the auxiliary outputs on the 2-point models are used for cooling control.
On the 4-point models, heating/cooling control can be performed for two input points only.
2 event input M3 screws EJ1N-TC2A-CNB
Basic unit 2 2 current 2 transistor (NPN)
2
For heating/cooling control applications, the auxiliary outputs on the 2-point models are used for cooling control.
On the 4-point models, heating/cooling control can be performed for two input points only.
2 event input Screw-less clamp EJ1N-TC2B-CNB
Basic unit 4 4 voltage (pulse) M3 screws EJ1N-TC4A-QQ
Basic unit 4 4 voltage (pulse) Screw-less clamp EJ1N-TC4B-QQ
High function unit 4 transistor (NPN) 4 event input M3 screws EJ1N-HFUA-NFLK
High function unit 4 transistor (NPN) 4 event input Screw-less clamp EJ1N-HFUB-NFLK
DeviceNet unit Screw connector EJ1N-HFUB-DRT
Ethernet unit
2
This unit mounts to the left of the CelciuX° (EJ1) configuration and enables PROFINET or Modbus/TCP network connection.
Combine the HFU-ETN with an EDU_-NFLK end unit to use with other devices supporting Modbus-RTU like E5_N temperature controllers and MX2 Inverters.
3 x RJ45 EJ1N-HFU-ETN
End unit
2
An End unit is always required for connection to a Basic unit or an HFU. An HFU cannot operate without a Basic unit.
2 transistor (NPN) M3 screws EJ1C-EDUA-NFLK
End unit
2
An End unit is always required for connection to a Basic unit or an HFU. An HFU cannot operate without a Basic unit.
2 transistor (NPN) Removable Connector EJ1C-EDUC-NFLK

Accessories

Current transformer

Diameter Order code
5.8 dia. E54-CT1
12.0 dia. E54-CT3

Communications and cables

Description Order code
G3ZA connecting cable 5 meter EJ1C-CBLA050
USB programming cable E58-CIFQ1
PC based configuration and tuning software CX-Thermo EST2-2C-MV4
PROFIBUS Gateway PRT1-SCU11

Specifications

Item Type EJ1_-TC2 EJ1_-TC4
Power supply voltage 24 VDC
Operating voltage range 85% to 110% of rated voltage
Power consumption 4 W max. (at maximum load) 5 W max. (at maximum load)
Input (see note)
2
Inputs are fully multi-input. Therefore, platinum resistance thermometer, thermocouple, infrared thermosensor, and analog input can be selected.
Thermocouple: K, J, T, E, L, U, N, R, S, B, W, PLII
ES1B Infrared Thermosensor: 10 to 70°C, 60 to 120°C, 115 to 165°C, 140 to 260°C.
Analog input: 4 to 20 mA, 0 to 20 mA, 1 to 5 V, 0 to 5 V, 0 to 10 VPlatinum resistance thermometer: Pt100, JPt100
Input impedance Current input: 150Ω max., voltage input: 1 MΩ min.
Control outputs Voltage output Output voltage: 12 VDC ±15%, max. load current: 21 mA (PNP models with short-circuit protection circuit)
Transistor output Max. operating voltage: 30 V, max. load current: 100 mA
Current output Current output range: 4 to 20 mA or 0 to 20 mA DC Load: 500 Ω max. (including transfer output)(Resolution: Approx: 2,800 for 4 to 20 mA DC, approx. 3,500 for 0 to 20 mA DC)
Event inputs Input points 2
Contact input ON: 1 kΩ max., OFF. 100 kΩ min.
Non-contact input ON: Residual voltage: 1.5 V max., OFF: Leakage current: 0.1 mA max.
Outflow current: approx. 4 mA per point
Number of input and control points Input points: 2, control points: 2 Input points: 4, control points: 4
Setting method Via communications
Control method ON/OFF control or 2-PID (with autotuning, selftuning, Heat & Cool autotuning and non-linear cool output selection)
Other functions Two-point input shift, digital input filter, remote SP, SP ramp, manual manipulated variable,
manipulated variable limiter, interference overshoot adjustment, loop burnout alarm, RUN/STOP, banks, I/O allocations, etc.
Alarm output 2 points via End unit
Communication RS-485, PROFIBUS, Modbus, DeviceNet RS-485, PROFIBUS, Modbus, DeviceNet
Size in mm (W×H×D) 31×96×109
Weight 180 g
Ambient temperature range Operating –10 to 55°C, Storage –25 to 65°C (with no icing or condensation)
Ambient humidity range Operating 25% to 85% (with no condensation)

Dimensions

Item Size in mm (H×W×D)
EJ1N-HFU_-NFL_ 95.4×31.0×104.9/109.0
EJ1N-HFUB-DRT 90.9×31.0×82.2
EJ1C-EDU 95.4×15.7×76.2/79.7

How can we help you?

If you have a question or would like to ask for a quote, please contact us or send a request.

+47 22 65 75 00
Contact us

Kontakt meg EJ1N

ej1n product image 400x400 en prod

Vennligst fyll inn alle obligatoriske felter. Dine personlige opplysninger vil bli behandlet konfidensielt.

Text error notification

Text error notification

Text error notification

Text error notification

Country error notification

Text area error notification

Checkbox error notification

Checkbox error notification

Takk for din forespørsel. Vi vil kontakte deg så snart som mulig.

Vi har for tiden tekniske problemer. Ditt skjema har ikke blitt innsendt. Vi beklager så mye og håper du vil prøve igjen senere. Detaljer:

Download
+47 22 65 75 00
+47 22 65 75 00
Request quotation
Request quotation

Tilbud for EJ1N

Ved å fylle ut dette skjemaet vil du motta et tilbud på det valgte produktet. Vennligst fyll inn alle obligatoriske felter. Dine personlige opplysninger vil bli behandlet konfidensielt.

ej1n product image 400x400 en prod

Personlige opplysninger

EJ1N

Text error notification

Text error notification

Text error notification

Text error notification

Country error notification

Tilbudsdetaljer

Select notification error

Select notification error

Text area error notification

Checkbox error notification

Checkbox error notification

Takk for din tilbudsforespørsel. Vi vil sende deg det forespurte tilbudet så snart som mulig.

Vi har for tiden tekniske problemer. Ditt skjema har ikke blitt innsendt. Vi beklager så mye og håper du vil prøve igjen senere. Detaljer:

Download
Request quotation
Request quotation

Expertise

Reduce Crossover Wiring with Horizontal Connection Structure

Simply connect power supply line and RS485 to end unit module to  power up the entire system and distribute RS485 network to all attached EJ1N-TC modules (save 4 wires for each module connected side by side)

Heaters diagnostic

Electric heaters are the most common way to warm up several process as oven, extruder, sealing machines. Potential heater fault can create a lot of problem during production. EJ1N is equipped with a full set of alarm for detecting heater burnout/Solid State fault/ heater overcurrent even in 3phase wiring scenario up to 100A.

Temperature fluctuation rejection

EJ1N is equipped with an effective  algorithm that support PID control to mitigate external disturbance impacts . The Disturbance Overshoot Adjustment Function adjusts the control waveform when an external disturbance happen.
